Evaluation of the value status in PCS 7
The value status is evaluated via the PCS 7 channel driver.
1. The PCS 7 channel driver reads the value status from the process image of the inputs...
2. ...and uses it to form the quality code for PCS 7.
For a detailed description of the evaluation and processing of the respective input signals, refer
to the help for the block library.
See also
Digital input module (Page 435)
PCS 7 documentation (
https://support.automation.siemens.com/WW/view/en/
10806846/130000)
7.7 Diagnostic interrupts of the transceiver
Diagnostic block OB82
Diagnostics of the interface module
OB82 is called if an incompatible transceiver is plugged in.
Diagnostics of the transceiver
Commissioning and Diagnostics
7.7 Diagnostic interrupts of the transceiver
ET 200iSP
Operating Instructions, 11/2022, A5E00247483-AK 167
