The service data can be read out from the following FW version of the interface module:
• PROFINET IM 152-1PN: As of FW version V1.0.0
• PROFIBUS IM 152-1DP: As of FW version V2.0.5
You can read out the service data with the menu command "PLC -> Save service data", save it in a
󹪝le and forward it to Customer Support.
Requirements
You must have STEP 7 as of V5.3 installed to use this function.
Note the following:
• If possible, save the service data immediately after the ET 200iSP station has failed.
• Establish a network connection to the interface module:
– Connection via media converter and PROFINET IO to the IM 152-1PN
– Direct connection via RS 485-IS coupler and PROFIBUS RS 485-IS to the IM 152-1DP
Note
Connect the PG to the PROFIBUS DP and access the IM 152-1DP via the RS 485-IS coupler
(of the intrinsically safe PROFIBUS RS 485-IS).
• In the redundant con󹪝guration, it is su󹪟cient to establish the connection to one of the two
interface modules.
Procedure
1. In the SIMATIC Manager, select "PLC > Show accessible devices".
2. Select the a󹪜ected station.
3. Select the "PLC > Save service data" menu command.
In the next dialog box, select the 󹪝le path and the 󹪝le names for the service data.
4. Save the 󹪝le.
5. Forward these 󹪝les to Customer Support on request.
8.10 Resetting the IM 152-1PN to factory settings using STEP 7
Requirements
• There is a direct connection to the interface module.
• The con󹪝guration tool is open.
Maintenance
8.10 Resetting the IM 152-1PN to factory settings using STEP 7
ET 200iSP
236 Operating Instructions, 11/2022, A5E00247483-AK
