Error type Error text Meaning Remedy
11010
B
26
D
External fault
• Encoder error
• Encoder supply faulty
• Changeover contact error
• Actuator error
• HART eld device error
• Replacement of encoder/
actuator/HART eld device
• Correction of the process
wiring
11011
B
27
D
HART congura‐
tion modied
(HART warning)
--- ---
11101
B
29
D
HART main varia‐
ble outside of the
limits (HART diag‐
nostics)
--- ---
11110
B
30
D
HART non-primary
variable outside of
the limits (HART di‐
agnostics)
--- ---
Note
Control response
A control behavior is implemented in the electronic modules of the ET 200iSP for parameter
assignment.
If the electronic module receives a faulty parameter, this is rejected. The electronic then
continues to operate with its already valid parameters (the default parameters from the initial
parameter assignment). A "Parameterization error" diagnostic message is not output.
7.12.6 Diagnostics for incorrect conguration states of the ET 200iSP with PROFINET
Incorrect conguration states
The following incorrect expansion states of the ET 200iSP lead to a station failure of theET 200iSP
or prevent entry into the data exchange. These reactions are independent of the release of the
interface module parameter "Operation at setpoint <> actual conguration":
• Two missing electronic modules
• Terminating module missing
• Number of modules exceeds maximum conguration
• Faulty backplane bus (e.g. defective terminal module)
Note
If a module is missing (gap) and the ET 200iSP POWER OFF/POWER ON is switched, then the
ET 200iSP starts. The startup with more than one missing module is not possible. If more than
one electronic module is missing, then after plugging in these modules a safe start-up of the
ET 200iSP is only guaranteed after POWER OFF/ POWER ON.
Commissioning and Diagnostics
7.12 Diagnostics with STEP 7 with PROFINET
ET 200iSP
196 Operating Instructions, 11/2022, A5E00247483-AK
