10.2 Terminal Modules TM-PS-A and TM-PS-B
Article number
Type Article number
TM‑PS‑A 6ES7193-7DA10-0AA0, only still available as spare part
TM‑PS‑A 6ES7193-7DA20-0AA0
TM‑PS‑B 6ES7193-7DB10-0AA0, only still available as spare part
TM‑PS‑B 6ES7193-7DB20-0AA0
Properties
• Terminal module for Power Supply PS
• Current infeed for the entire ET 200iSP station
• Connected using screw terminals
• 3 terminals for connection of the supply voltage/ equipotential bonding
• Prewiring of the terminal module is possible
• Self-generating interference leakage from the terminal module to the DIN rail by means of a
spring contact
• Reverse polarity protection is ensured by the power supply module (only for PS DC24V)
Note
On the terminal modules TM‑PS‑A/TM‑PS‑B (6ES7193-7DA10-0AA0/6ES7192-7DB10-0AA0)
only the power supply PS as of article number 6ES7138-7EA01-0AA0 can be plugged in.
Plugging in the predecessor power supply PS with article number 6ES7138-7EA00-0AA0 is
prevented by corresponding coding.
Compatibility with predecessor modules
Terminal modules
TM‑PS‑A
TM‑PS‑B
Power supply PS DC24V
6ES7138-7EA01-0AA0 up to
product version 6
Power supply PS DC24V
6ES7138-7EA01-0AA0 prod‐
uct version 7 and higher
Power supply PS
AC120/230V
6ES7138-7EC00-0AA0 as of
product version 1
6ES7193-7DA10-0AA0 X X ---
6ES7193-7DB10-0AA0 X X ---
6ES7193-7DA20-0AA0 --- X X
6ES7193-7DB20-0AA0 --- X X
Terminal modules
10.2 Terminal Modules TM-PS-A and TM-PS-B
ET 200iSP
250 Operating Instructions, 11/2022, A5E00247483-AK
