12.2.2 Parameters for IM 152-1DP
Parameters
The procedure for setting parameters is described in the Chapter "Commissioning (Page 155)".
Table 12-2 Parameter for the interface module IM 152-1DP
Parameters IM 152-1DP Range of values Default Applicability
Operation at Preset <> Actual
Con󹪝guration
• disable
• enable
disable ET 200iSP
Self-diagnosis
• disable
• enable
disable ET 200iSP
Redundant power supply di‐
agnostics
• No redundant power sup‐
ply
• Redundant Power Supply
• Redundant Power Supply
required
No redundant power supply ET 200iSP
Diagnostic interrupts
1
• disable
• enable
disable ET 200iSP
Hardware interrupts
1)
• disable
• enable
disable ET 200iSP
Time stamping (enable pa‐
rameter)
2
• Yes
• No
No ET 200iSP
Edge evaluation event enter‐
ing state
2
• Rising edge (0-->1)
• Falling edge (1-->0)
• Channel-speci󹪝c
Rising edge (0-->1) ET 200iSP
Data format
• SIMATIC S7
SIMATIC S7 ET 200iSP
Noise suppression
• 50 Hz
• 60 Hz
50 Hz ET 200iSP
Temperature unit
• Celsius
• Fahrenheit
Celsius ET 200iSP
Slot reference junction 1 to 2
• None
• 4 to 35
None ET 200iSP
Input reference junction 1 to 4
• RTD on channel 0
• RTD on channel 1
• RTD on channel 2
• RTD on channel 3
RTD on channel 0 ET 200iSP
1
It may or may not be possible to edit these parameters, depending on the con󹪝guration tool used.
2
Con󹪝gurable only in HW Con󹪝g and when you operate the ET 200iSP as an S7 DP device.
Network interface module
12.2 PROFIBUS interface module IM 152-1DP
ET 200iSP
288 Operating Instructions, 11/2022, A5E00247483-AK
