Con󹪝gurations (principle)
4
4.1 Modular system
Modular system
With ET 200iSP, modular means: You can adapt the design to your applications by using
4‑channel and 8‑channel electronic modules.
Example
The following 󹪝gure shows an example of the con󹪝guration of the ET 200iSP distributed I/O
device:
4XJUDIFTTFOTPST
/".63TFOTPS
$PVOUQVMTFGSFRVFODZ
7BMWFTSFMBZT
XJSFUSBOTNJUUFS
3FTJTUBODFUIFSNPNFUFS
5IFSNPDPVQMFT
)"35꫼FMEEFWJDFT
-PBETBUDVSSFOUPVUQVU
Figure 4-1 Con󹪝guration example ET 200iSP
ET 200iSP
Operating Instructions, 11/2022, A5E00247483-AK 59
