$POWFSTJPOUJNFDIBOOFM
$ZDMFUJNF
$POWFSTJPOUJNFDIBOOFM
$POWFSTJPOUJNFDIBOOFM
$POWFSTJPOUJNFDIBOOFM
Figure A-8 Cycle time of the analog input module
A.3.6 Reaction times for analog output modules
Conversion time
The conversion time of the analog output channels includes the transfer of the digitized output
values from the internal memory and the digital-to-analog conversion.
Cycle time
The conversion of the analog output channels is performed for the module with a processing
time and sequentially with a conversion time for channels 0, 1, 2 and 3.
The cycle time, i.e. the time until an analog output value is converted again, is the sum of the
conversion times of all activated analog output channels and the processing time of the analog
output module.
The following gure shows an overview of how the cycle time for an analog output module is
composed.
Appendix
A.3 Reaction times
ET 200iSP
Operating Instructions, 11/2022, A5E00247483-AK 433
