3.5 Installing the the Sample Con󹪝guration
3.5.1 Installing the ET 200iSP
Installing the ET 200iSP
1. Install the mounting rail (480 mm) into the enclosure which has been mounted on a solid
base.
2. Install the modules starting at the left-hand end of the DIN rail. Start with the terminal
module TM-PS-A (hook in - swivel in - 2 x screw on). Continue with the remaining modules
(󹪝t onto top of rail - push in at the bottom - push to the left). Insert the modules in the
following order:
– Terminal module TM-PS-A
– Terminal module TM-IM/EM
– Terminal module TM-EM/EM
– Terminating module
3.5.2 Installing the S7-400
Installing the S7-400
1. Install the rack on a stable surface. See operating instructions Automation System S7-400:
Hardware and Installation (
https://support.automation.siemens.com/WW/view/en/
1117849)
2. On the left of the rack, start by installing the separate modules (hang in - swivel into position
- screw on tightly). Insert the modules in the following order:
– Power supply module PS
– Central processing unit CPU
3.5.3 Installing RJ45/FOC media converter or RS 485-IS coupler
The installation of the component depends on the selected con󹪝guration:
• With a PROFINET system, you need to connect the IM 152-1PN to a PROFINET IO via a 󹪝ber-
optic cable and a media converter (e.g. RJ45/FOC) with an intrinsically safe output.
• With a PROFIBUS system, you need to connect the IM 152-1DP to PROFIBUS DP via an
intrinsically safe PROFIBUS RS 485-IS and an RS 485-IS coupler.
Commissioning guideline
3.5 Installing the the Sample Con󹪝guration
ET 200iSP
42 Operating Instructions, 11/2022, A5E00247483-AK
