Siemens SIMATIC ET 200iSP User Manual

Parameter Range of values Default Applicability
4 AI I 2WIRE HART 4 AI I 4WIRE HART
Channel
• 0
• 1
• 2
• 3
0 Channel
IEEE variable,
• None
• Primary variable
• 1st non-primary varia‐
ble
• 2nd non-primary varia‐
ble
• 3rd non-primary varia‐
ble
None Channel
HART warning
• Enabled
• Disabled
Disabled Module
HART diagnostics
• Enabled
• Disabled
Disabled Module
14.11.2 Parameters relevant for 4 AI RTD, 4 AI TC analog electronics modules
Parameters 4 AI RTD, 4 AI TC
Table 14-41 Parameter 4 AI RTD, 4 AI TC
Parameters Range of values Default Applicability
4 AI RTD 4 AI TC
Hardware interrupt (on limit violation)
1
• Enabled
• Disabled
Disabled Channel
Measurement type ---
• Disabled
• RTD 4-wire connection
• RTD 3-wire connection
• RTD 2-wire connection
• R-4-wire connection
• R-3-wire connection
• R-2-wire connection
RTD 4-wire connec‐
tion
Channel
Analog electronic modules
14.11 Parameters of the analog electronic modules
ET 200iSP
402 Operating Instructions, 11/2022, A5E00247483-AK
