A.4.7 Analog output module with HART (4 AO I HART)
Address space of analog output module with HART (4 AO I HART)
Table A-28 PIQ with analog output module with HART (S7 format)
PIQ 7 6 5 4 3 2 1 0 Analog value
QB x Output value channel 0
QB x+1
QB x+2 Output value channel 1
QB x+3
QB x+4 Output value channel 2
QB x+5
QB x+6 Output value channel 3
QB x+7
Table A-29 PII for analog output module with HART (IEEE754 󹪞oating point format)
PII 7 6 5 4 3 2 1 0 Description
IB x IEEE variable 1 in 󹪞oating
point representation, as
speci󹪝ed for HART
You can select the number of
IEEE variables in the con󹪝gu‐
ration.
You can map any IEEE varia‐
ble of a 󹪝eld device into the
PII. See section "IEEE tags
(Page 396)"
IB x+1
IB x+2
IB x+3:
IB x+4 HART status byte for IEEE var‐
iable 1, as speci󹪝ed for HART.
See section "IEEE tags
(Page 396)"
IB x+5
...
IB x+9
IEEE variable 2 in 󹪞oating
point representation, as
speci󹪝ed for HART and HART
status byte (for con󹪝gura‐
tion see IEEE variable 1)
IB x+10
...
IB x+14
IEEE variable 3 in 󹪞oating
point representation, as
speci󹪝ed for HART and HART
status byte (for con󹪝gura‐
tion see IEEE variable 1)
IB x+15
...
IB x+19
IEEE variable 4 in 󹪞oating
point representation, as
speci󹪝ed for HART and HART
status byte (for structure see
IEEE variable 1)
HART status byte: Status codes used by the PROFIBUS PA pro󹪝le for ET 200iSP:
• 01001100 (4C
H
) uncertain, initial value (before 󹪝rst contact)
• 00011000 (18
H
) bad, no communication (communication error)
• 00001100 (0C
H
) bad, device failure (device fault)
Appendix
A.4 Address space of the inputs and outputs
ET 200iSP
Operating Instructions, 11/2022, A5E00247483-AK 441
