7.10 Status and error LEDs on the electronic modules of the ET 200iSP

Digital electronic modules





















SF Group error (red)

① Status for input/output status (green)

② Status for the input status (green)

Digital electronic module 2 DO Relay





SF Group error (red)

① Status for input/output status (green)

Commissioning and Diagnostics

7.10 Status and error LEDs on the electronic modules of the ET 200iSP

ET 200iSP

Operating Instructions, 11/2022, A5E00247483-AK 175
