CCC Ex e [ia Ga/ib] IIC T4 Gb
Ex e [iaD] IIC T4 Gb
UKCA DEKRA 21UKEX0032
See also
https://www.iecex.com (
https://www.iecex.com)
https://support.industry.siemens.com (https://support.industry.siemens.com)
10.4 Terminal module TM-IM/IM
Article number
6ES7193-7AB00-0AA0
Properties
• Terminal module for two interface modules (left and right side) with redundancy of the
interface modules:
– IM 152-1PN
6ES7152-1BA00-0AB0
– IM 152-1DP
6ES7152-1AA00-0AB0
• PROFIBUS RS 485‑IS connection via two 9-pole Sub D sockets
• Self-generating interference leakage from the terminal module to the mounting rail by
means of spring contacts
• Prewiring of the terminal module is possible
Note
The cable shield of the PROFIBUS DP cable is operationally connected to the equipotential
bonding via the spring contact to the mounting rail.
Note
The D-sub sockets of the IM 152-1PN are not connected within the IM 152-1PN.
Terminal modules
10.4 Terminal module TM-IM/IM
ET 200iSP
258 Operating Instructions, 11/2022, A5E00247483-AK
