There can be more than one diagnostic message at the same time.
Table 7-17 Diagnostic messages, their meaning and possible remedies
Diagnostic message Channel
error type
(CET)
Extended
channel er‐
ror type
(ECET)
Meaning Remedy
Con󹪝guration error: Un‐
supported transceiver in
port <port number>
0x602 0x6A0 Transceivers have been plugged
in that are not approved for use in
IM 152-1PN.
Replace the transceiver with a sup‐
ported SFP transceiver.
Con󹪝guration error: The
con󹪝guration of redun‐
dant interface modules
di󹪜ers.
0x602 0x6A1 The con󹪝guration of the interface
modules di󹪜er.
Check the consistency of the con‐
󹪝guration.
Con󹪝guration error: IO
data is suppressed
0x602 0x6A2 IO data is suppressed because a
con󹪝gured event has occurred.
Bring the station into the state ex‐
pected by the con󹪝guration.
Redundancy error: Pow‐
er supply unit <item>
missing or is not availa‐
ble
0x630 0x6D1 Problem with power supply. Check the power supply for possi‐
ble errors, e.g. overload, short-cir‐
cuit.
Replace the power supply if neces‐
sary.
Redundancy error: Re‐
dundancy partners have
di󹪜erent hardware/󹪝rm‐
ware versions
0x630 0x6D3 The HW/FW version of the redun‐
dant IO modules is inconsistent.
Replace the module or update the
󹪝rmware.
7.12.5 Error types of the electronic modules with PROFINET
Table 7-18 Error types of the electronic modules
Error type Error text Meaning Remedy
00001
B
1
D
Short-circuit
• Sensor line short circuited to P
potential
• Sensor line short circuited to
M potential
• Output line short circuited to P
potential
• Output line short circuited to
M potential
Correction of the process wiring
Encoder is defect Exchange the encoder
Incorrect encoder type con󹪝gured Correction of the con󹪝guration
Output overloaded Eliminate overload
00010
B
2
D
Undervoltage
(HART diagnostics)
HART analog output current set
(HART diagnostics)
---
00100
B
4
D
Overload (HART di‐
agnostics)
HART analog output current satu‐
rated (HART diagnostics)
---
Commissioning and Diagnostics
7.12 Diagnostics with STEP 7 with PROFINET
ET 200iSP
194 Operating Instructions, 11/2022, A5E00247483-AK
