Siemens SIMATIC ET 200iSP User Manual

7.13.12 Error types of the electronic modules with PROFIBUS
Table 7-37 Error types of the electronic modules
Error type Error text Meaning Remedy
00001
B
1
D
Short-circuit
• Sensor line short circuited to P
potential
• Sensor line short circuited to
M potential
• Output line short circuited to P
potential
• Output line short circuited to
M potential
Correction of the process wiring
Encoder is defect Exchange the encoder
Incorrect encoder type con󹪝gured Correction of the con󹪝guration
Output overloaded Eliminate overload
00010
B
2
D
Undervoltage
(HART diagnostics)
HART analog output current set
(HART diagnostics)
---
00100
B
4
D
Overload (HART di‐
agnostics)
HART analog output current satu‐
rated (HART diagnostics)
---
00110
B
6
D
Wire break
• Signal line to an encoder inter‐
rupted
• Signal line to an actuator in‐
terrupted
• Encoder supply line interrup‐
ted
Correction of the process inter‐
connection
Error on the external circuit (re‐
sistance)
Eliminate errors
Encoder is defect Exchange the encoder
Incorrect encoder type con󹪝gured Correction of the con󹪝guration
Input/output channel is unused
(open)
Deactivation of the "Diagnostic
Group Diagnostics" parameter
for this output channel
Load impedance is too large Use actuator with lower load
impedance
00111
B
7
D
High limit excee‐
ded
Value is above the overrange
• Correction tuning of mod‐
ule/actuator
• Modify measuring range by
means of con󹪝guration
01000
B
8
D
Lower limit excee‐
ded
Value is below the overrange
• Correction tuning of mod‐
ule/actuator
• Modify measuring range by
means of con󹪝guration
01001
B
9
D
Error Encoder signal 󹪞utters Eliminate cause of error
Hardware error in the module Exchange of the module
EMC interference Eliminate cause of error
Commissioning and Diagnostics
7.13 Diagnostics with STEP 7 with PROFIBUS
ET 200iSP
Operating Instructions, 11/2022, A5E00247483-AK 209
