Module Article number Compatible
4 DO DC17.4V/40mA shut down "H" 6ES7132-7RD22-0AB0 Yes
4 DO DC23.1V/20mA shut down "L" 6ES7132-7GD00-0AB0 Yes
4 DO DC17.4V/27mA shut down "L" 6ES7132-7GD10-0AB0 Yes
4 DO DC17.4V/40mA shut down "L" 6ES7132-7GD20-0AB0 No
4 DO DC17.4V/40mA shut down "L" 6ES7132-7GD21-0AB0 Yes
4 DO DC25.5V/22mA shut down "L" 6ES7132-7GD30-0AB0 Yes
2 DO Relay UC60V/2A 6ES7132-7HB00-0AB0 Yes
4 AI I 2WIRE HART 6ES7134-7TD00-0AB0 Yes
4 AI I 4WIRE HART 6ES7134-7TD50-0AB0 Yes
4 AI RTD 6ES7134-7SD50-0AB0 No
4 AI RTD 6ES7134-7SD51-0AB0 Yes
4 AI TC 6ES7134-7SD00-0AB0 Yes
4 AO I HART 6ES7135-7TD00-0AB0 Yes
Reserve module 6ES7138-7AA00-0AA0 Yes
WATCHDOG 6ES7138-7BB00-0AB0 Yes
4 F-AI I 2WIRE Fail-safe 6ES7138-7FA00-0AB0 Yes
4 F-DO DC17.4V/40mA Fail-safe 6ES7138-7FD00-0AB0 Yes
8 F-DI NAMUR Fail-safe 6ES7138-7FN00-0AB0 Yes
12.2 PROFIBUS interface module IM 152-1DP
Article number
6ES7152-1AA00-0AB0
Properties
The interface module IM 152-1DP has the following properties:
• Connect ET 200iSP to PROFIBUS RS 485-IS
• Preparing the data for the installed electronic modules
• PROFIBUS address can be set via switches
• Operation as DPV0, S7 DP or DPV1 device
• The maximum address space is 244 bytes for inputs and 244 bytes for outputs.
• Update rmware via PROFIBUS DP
• Redundancy of the IM 152-1DP as of V2.0
• Switching o the supply voltage DC 24 V at the terminal module TM-PS-A also switches o
the interface module IM 152-1DP.
Network interface module
12.2 PROFIBUS interface module IM 152-1DP
ET 200iSP
Operating Instructions, 11/2022, A5E00247483-AK 283
