13.2 Digital electronics module 4 DO
Article numbers
Type Article number
4 DO DC23.1V/20mA shut down "H" 6ES7132-7RD01-0AB0
4 DO DC17.4V/27mA shut down "H" 6ES7132-7RD11-0AB0
4 DO DC17.4V/40mA shut down "H" 6ES7132-7RD22-0AB0
4 DO DC23.1V/20mA shut down "L" 6ES7132-7GD00-0AB0
4 DO DC17.4V/27mA shut down "L" 6ES7132-7GD10-0AB0
4 DO DC17.4V/40mA shut down "L" 6ES7132-7GD21-0AB0
4 DO DC25.5V/22mA shut down "L" 6ES7132-7GD30-0AB0
Properties
• 3 variants shut down "H" output modules
• 4 variants shut down "L" output modules
• 4 outputs per module
• Nominal load voltage DC 25.5V, 23.1V or 17.4V
• Outputs suitable for Ex i solenoid valves, DC relays and actuators
• To enhance performance, you can connect in parallel two digital outputs of electronic
modules 4 DO DC17.4V/27mA or 4 DO DC 17.4V/40mA for one actuator. This increased
power is permitted only on the same module and between the following channels:
– Channel 0 and channel 1 Jumper from terminal 1 to terminal 5; DO connection to terminal
3
– Channel 2 and channel 3 Jumper from terminal 9 to terminal 13; DO connection to
terminal 11
• You must connect an intrinsically safe shutdown signal to the actuator disconnection input.
This allow the simultaneous deactivation of all outputs of the electronic module. The
function does not a󹪜ect the process image output table (POI).
– Shut down "H" output modules: Deactivation via High active, intrinsically safe switching
signal.
– Shut down "L" output modules: Deactivation via Low active, intrinsically safe switching
signal.
Note
Note that shut down "H" output modules and shut down "L" output modules require
separate switching signal connections.
Digital electronic modules
13.2 Digital electronics module 4 DO
ET 200iSP
Operating Instructions, 11/2022, A5E00247483-AK 305
