Siemens SIMATIC ET 200iSP User Manual

Parameters Range of values Default Applicability
4 AI RTD 4 AI TC
Low limit Low to high limit of the overrange
(SIMATIC S7)
Low limit Channel
1
Refers to "High limit" and "Low limit" parameters
2
If short-circuit diagnostics is enabled, then no under󹪞ow is displayed.
14.11.3 Parameters for analog electronic module 4 AO I HART
Con󹪝guration with STEP 7 as of V5.3 SP1 and current hardware update
For description, see online help STEP 7.
Con󹪝guration with GSD 󹪝le
There are di󹪜erent con󹪝gurations for the 4 AO I HART analog electronic module, which you can
select via the following entries in the hardware catalog of the con󹪝guration software:
• Con󹪝guration "4 AO I HART":
The analog values are shown in S7 format.
• Con󹪝gurations "4 AO I +x":
The analog values are shown in S7 format. In addition, up to 4 IEEE variables (primary or non-
primary variable) are available in IEEE 754 format. You select the number of IEEE variables (1
to 4) via the con󹪝guration:
– ...I +1
– ...I +2
– ...I +3
– ...I +4
Parameters for con󹪝guration "4 AO I HART"
Table 14-42 Parameters for con󹪝guration "4 AO I HART"
Parameter Range of values Default Applicability
Group diagnostics
• Enabled
• Disabled
Enabled Module
Diagnostics: wire break
• Enabled
• Disabled
Enabled Channel
Diagnostics: short-circuit
• Enabled
• Disabled
Enabled Channel
Analog electronic modules
14.11 Parameters of the analog electronic modules
ET 200iSP
404 Operating Instructions, 11/2022, A5E00247483-AK
