7.12.4 Diagnostics of the IM 152-1PN
Diagnostic options
A wide range of information and tools are available for diagnosing the status of the IM 152-1PN.
• Displays
Some LED displays are located on the front of the IM 152-1PN. This provides you with an
overview of the status of the IM 152-1PN. You can 󹪝nd information on this in section "Status
and error LEDs on the IM 152-1PN (Page 170)".
• Tools
Information about the most important tools for diagnosing PCS 7 systems is available in the
Service Manual PCS 7 Process Control System; Service Support and Diagnostics
(
www.siemens.com/pcs7-documentation).
– Maintenance Station
With the Maintenance Station, PCS 7 o󹪜ers you the possibility to call up information about
the status of all the PCS 7 components in hierarchically structured diagnostics screens. For
this, the data of a component is analyzed with the existing online functions of the
associated tools. You can access the ES data from the diagnostics screens (can be
controlled via access protection mechanisms).
– Module information
Select the IM 152-1PN in HW Con󹪝g.
Select the menu command PLC > Module information ... .
– Connection status
Called from Start menu Siemens SIMATIC programs: STEP 7 > NCM S7 > Diagnostics
– Inventory data
Called up via Siemens SIMATIC program: SIMATIC > SIMATIC Management Console
(license required) > Plant view > shortcut menu command "Determine inventory data"
– Status of 󹪝eld devices and bus lines
Called via SIMATIC PDM
The IM 152-1PN does not undertake any detailed diagnostics of 󹪝eld devices and bus
cables. Detailed diagnostics are possible, provided that the required device descriptions
are available in suitable programs (e.g. SIMATIC PDM).
Open SIMATIC PDM > Device > CFU <V...> Con󹪝guration.
Diagnostic messages
A diagnostics message is generated for each diagnostics event and the ER LED 󹪞ashes on the
module.
The diagnostic messages can, for example, be read from the diagnostic bu󹪜er of the CPU.
Commissioning and Diagnostics
7.12 Diagnostics with STEP 7 with PROFINET
ET 200iSP
Operating Instructions, 11/2022, A5E00247483-AK 193
