13.5.3 Digital electronic module 2 DO Relay UC60V/2A
Parameters 2 DO Relay UC60V/2A
Table 13-19 Parameters for 2 DO Relay UC60V/2A
Parameters Range of values Default Applicability
Response to CPU/ master STOP
• Use substitute value
• Keep last value
Use substitute value Channel
Substitute value
• 0
• 1
0 Channel
13.6 Description of the parameters of the digital electronic modules
13.6.1 Time stamping
Description
With this parameter you can enable time stamping channel by channel for each digital input of
the module. The time stamps are passed on from the ET 200iSP to the S7-400 or to the OS if you
also enable the "Time stamping" parameter in the IM 152-1DP.
Time stamping is only allowed for IM 152-1DP. Time stamping is not supported for IM 152-1PN.
13.6.2 Pulse stretching
Description
Pulse extension is a function for changing a digital input signal. A pulse at a digital input is
extended to at least the con󹪝gured length. If the input pulse is already longer than the
con󹪝gured length, then the pulse will not be changed.
Digital electronic modules
13.6 Description of the parameters of the digital electronic modules
ET 200iSP
Operating Instructions, 11/2022, A5E00247483-AK 339
