Note
The supplied voltage at the relay outputs must be protected with a circuit breaker 6 A and
tripping characteristic C.
13.4 Identi󹪝cation and maintenance functions (I&M)
Description
See section "Identi󹪝cation and maintenance data I&M (Page 77)".
13.5 Parameters of the digital electronic modules
13.5.1 Digital electronic module 8 DI NAMUR
Con󹪝guration with STEP 7 as of V5.3 SP1 and current hardware update
For description, see online help STEP 7.
Con󹪝guration with GSD 󹪝le
For the digital electronic module 8 DI NAMUR there are di󹪜erent con󹪝gurations that you can
select via the following entries in the hardware catalog of the con󹪝guration software:
• Con󹪝guration "8 DI NAMUR": 8 digital inputs
• Con󹪝guration "2 Count/ 6 DI NAMUR": 2 counters and 6 digital inputs
• Con󹪝guration "2 Count/ 6 Control": 2 counters and 6 control signals
• Con󹪝guration "2 Trace/ 6 DI NAMUR": 2 frequency meters and 6 digital inputs
Parameters 8 DI NAMUR, con󹪝guration "8 DI NAMUR"
Table 13-14 Parameters for "8 DI NAMUR"
Parameters Range of values Default Applicability
Time stamping
1
• Enabled
• Disabled
Disabled Channel
Edge evaluation of incoming
event
1
• Rising edge (0-->1)
• Falling edge (1-->0)
Rising edge (0-->1) Channel
Digital electronic modules
13.5 Parameters of the digital electronic modules
ET 200iSP
Operating Instructions, 11/2022, A5E00247483-AK 335
