10.1 Terminal modules and the suitable modules for them
Modules and terminal modules
The table below shows you which modules you can use on the various terminal modules.
Table 10-1 Modules and terminal modules
Modules Terminal modules
TM-PS-A
1)
TM-PS-B
1)
TM-PS-A
TM-PS-B
TM-IM/IM TM-IM/EM 60S
TM-IM/EM 60C
TM-IM/EM
TM-EM/EM 60S
TM-EM/EM 60C
TM-EM/EM
TM-RM/
RM 60S
Article number 6ES7193- 7DA10-0AA0
7DB10-0AA0
7DA20-0AA0
7DB20-0AA0
7AB00-0AA0 7AA00-0AA0
7AA10-0AA0
7AA20-0AA0
7CA00-0AA0
7CA10-0AA0
7CA20-0AA0
7CB00-0AA0
Power supply PS DC24V
(up to product version 6)
x
Power supply PS DC24V
(product version 7 and
higher)
x x
Power supply PS
AC120/230V
x
Interface module IM
152-1PN
x x x
Interface module IM
152-1DP
x x x
8 DI NAMUR x x x
4 DO DC23.1V/20mA x x x
4 DO DC17.4V/27mA x x x
4 DO DC17.4V/40mA x x x
2 DO Relay UC60V/2A x x
4 AI I 2WIRE HART x x x
4 AI I 4WIRE HART x x x
4 AI RTD x x x
4 AI TC x x x
4 AO I HART x x x
Reserve module x x x x
2)
x
2)
WATCHDOG x x x
1)
Only available as replacement part
2)
As of product version 3 of the reserve module
