Manufacturer's ID
Table 7-31 Con󹪝guration of the manufacturer's ID
Byte 4 Byte 5 Manufacturer ID for
81
H
10
H
IM 152-1DP
7.13.9 Identi󹪝er-related diagnostics in PROFIBUS
Evaluation of the device diagnostics
The following 󹪝gure describes a procedure of how you can systematically evaluate the device
diagnostics. You start with ID-related diagnostics.
Table 7-32 Evaluation of the device diagnostics
Byte 7 6 5 4 3 2 1 0 Description
Byte 6 Identi󹪝er-related diagnostics (byte 6)
Bit 6 and Bit 7:
• 01: Identi󹪝er-related diagnostics
• 10: See section "Channel-related diagnostics with PRO‐
FIBUS (Page 207)"
• 00: See next row
Byte 13/
Byte x+1
Module status (byte 13)/interrupts (byte x+1)
Bit 7:
• 1: See section "Module status in PROFIBUS (Page 206)"
• 0: See section "Interrupts in PROFIBUS (Page 212)"
De󹪝nition
The identi󹪝er-related diagnostics indicates whether modules of the ET 200iSP are faulty or not.
Identi󹪝er-related diagnostics starts at byte 6 and is 6 bytes long.
Identi󹪝er-related diagnostics:
The bits in slots 2, 4 through 35 (bytes 7 through 11) of the modules are set if one of the
following situations occurs:
• A module is removed.
• A module is inserted that was not con󹪝gured.
• An plugged module cannot be accessed.
• A module reports a diagnostics event.
Unused slots have the value "0" entered.
Commissioning and Diagnostics
7.13 Diagnostics with STEP 7 with PROFIBUS
ET 200iSP
Operating Instructions, 11/2022, A5E00247483-AK 205
