PLC sample applications
6.4.1
PLC sample application (turning)
This sample application is applicable to machines with the following configurations:
● Two axes: axes X and Z, with a hardware limit switch respectively in the positive and negative directions of each axis
● A spindle: SP
● HALL effect device turret with six working stations
● PLC-controlled timely and quantitatively lubrication system
● PLC-controlled cooling system
Assignment of inputs and outputs
Limit switch in the "+" direction of axis X
Limit switch in the "-" direction of axis X
I0.3 - Reserved
I0.5 Limit switch in the "+" direction of axis Z Normally closed
Limit switch in the "-" direction of axis Z
Reference point switch of axis X
Reference switch of axis Z
Tool path detecting signal T1
Tool path detecting signal T2
Tool path detecting signal T3
Tool path detecting signal T4
Tool path detecting signal T5
Tool path detecting signal T6
Reserved for other types of turrets
Cooling pump motor overload
Lubrication pump motor overload
I3.0 - Reserved
I3.2 - Reserved
Handheld unit: axis X selected
Handheld unit: axis Y selected
