17.5.3
Active alarm response
DB1600
Active alarm response [r]
PLC -> HMI interface
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
2000 Acknowledge
POWER ON
Acknowledge
with
DB1600DBX3
000.0
PLC STOP EMERGENCY
STOP
Feedrate
disable all
axes
Read-in
disable
NC start
disable
2001
2002
2003
17.5.4
Alarm acknowledgement
DB1600
Alarm acknowledgement [r/w]
PLC -> HMI interface
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
3000
Ack
3001
3002
3003
17.6
Signals from/to HMI
17.6.1
Program control signals from the HMI (retentive area)
DB1700
Signals, HMI [r/w]
HMI -> PLC interface
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0 Dry run
feedrate
selected
M01 se-
lected
DRF se-
lected
1 Program
test selected
Feedrate
override
selected for
rapid trav-
erse
2 Skip block 7
selected
Skip block
6 selected
Skip block
5 selected
Skip block
4 selected
Skip block
3 selected
Skip block
2 selected
Skip block
1 selected
Skip block
0 selected
3 Measure-
ment in JOG
active
Calculation
of meas-
urement
value not
finished
Skip block
9 selected
Skip block
8 selected
4
5
6
7
Reset
NC stop
NC start
