Commissioning Manual
6FC5397-4EP10-0BA8, 07/2018
377
Shock Operation Operational area: II
Ambient classification: 3M2
Peak acceleration: 5 g + 15 g
Duration: 30 ms + 11 ms
Quantity of shocks: 3
Summed shocks: 18
Transport &
Covered by vibration test
Vibration Operation Operational area II/3M2
10 Hz to 58 Hz: 0.075 mm deflection
58 Hz to 200 Hz: 1g vibration
Transport &
storage
5 Hz to 9 Hz: 3.5 mm deflection
9 Hz to 200 Hz: 1 g vibration
Ambient Classification: 1M2
Certification
Outline dimensions (W × H × D, mm) 100 × 180
140 × 260 × 240 190 × 350 × 185
The values here are given at rated load.
2)
The overvoltage threshold is 820 VDC; the undervoltage threshold is 320 VDC.
Permissible line supplies dependent on the installation altitude
● For installation altitudes ≤ 2000 m above sea level, it is permissible to connect the V70 drive to any of the line supplies
that are specified for it.
● For installation altitudes 2000 m to 5000 m above sea level, you must connect a V70 drive to any of the specified line
supplies either via an isolating transformer or with a grounded neutral point.
