Siemens SINUMERIK 808D ADVANCED Series User Manual

Commissioning Manual
6FC5397-4EP10-0BA8, 07/2018
425
DB3000
Mode signals to NCK [r/w]
PLC -> NCK interface
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0 Reset Mode
change
block
Mode
JOG MDI AUTO
1
Single block
Machine function
Type A
Type B
REF
2
Machine function
1)
Continuous
traversing
Var. INC 10000 INC 1000 INC 100 INC 10 INC 1 INC
3
1)
To use the machine function signals in DB3000.DBB2, you must set the "INC inputs in the operating-mode signal range
active" signal (DB2600.DBX1.0) to "1".
DB3100
Mode signals from NCK [r]
NCK -> PLC interface
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0 Reset 808
READY
Mode
JOG
MDI
AUTO
1
Active machine function
REF
2
Machine function
Continuous
traversing
active
Var. INC
active
10000 INC
active
1000 INC
active
100 INC
active
10 INC
active
1 INC ac-
tive
3
17.9
Channel signals
17.9.1
Signals to NC channel
Control signals to NC channel
DB3200
Signals to NCK channel [r/w]
PLC -> NCK interface
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0 Activate
test run
feedrate
Activate
M01
Activate
single block
1)
Activate
DRF
Activate
traverse
forwards
Activate
traverse
backwards
1 Activate
program
test
Enable
protection
zones
Activate
referencing
2
Activate skip block
7
6
5
4
3
2
1
0
3
4
Feedrate offset
2)
H
G
F
E
D
C
B
A
5
Rapid traverse override
H
G
F
E
D
C
B
A
