15.3
Servo motors
15.3.1
SIMOTICS S-1FL6 feed motors
General technical data
Parameter
Description
Type of motor
Permanent-magnet synchronous motor
Cooling
Self-cooled
Operating temperature
0 °C to 40 °C (without power derating)
Storage temperature
-20 °C to +65 °C
Relative humidity
≤ 90% (non-condensing at 30 °C)
Installation altitude
≤ 1000 m (without power derating)
Maximum noise level
1FL604❑: 65 dB; 1FL606❑: 70 dB; 1FL609❑: 70 dB
Thermal class
B
Vibration resistance
≤ 49 m/s
2
Shock resistance ≤ 25 m/s
2
(continuous in axial direction); ≤ 50 m/s
2
(continuous in
radial direction); ≤ 250 m/s
2
(in a short time of 6 ms)
Holding brake
Rated voltage
24 V ± 10%
Rated current
1FL604❑: 0.88 A
1FL606❑ : 1.44 A
1FL609❑: 1.88 A
Holding brake torque
1FL604❑: 3.5 Nm
1FL606❑ : 12 Nm
1FL609❑: 30 Nm
Maximum brake opening time
1FL604❑: 60 ms
1FL606❑ : 180 ms
1FL609❑: 220 ms
Maximum brake closing time
1FL604❑: 45 ms
1FL606❑ : 60 ms
1FL609❑: 115 ms
Maximum number of emergency
stops
2000
1)
Bearing lifetime > 20000 h
2)
Oil seal lifetime
5000 h
Encoder lifetime
> 20000 h
3)
Paint finish
Black
Degree of protection
IP65, with shaft oil seal
Type of construction
IM B5, IM V1 and IM V3
Positive rotation
Clockwise (default setting in SINAMICS V70 feed drives)
Certification
1)
Restricted emergency stop operation is permissible. Up to 2000 braking operations can be executed with 300% rotor
moment of inertia as external moment of inertia from a speed of 3000 RPM without the brake being subject to an inad-
missible amount of wear.
2)
This lifetime is only for reference. When a motor keeps running at rated speed under rated load, replace its bearing after
20,000 hours to 30,000 hours of service time. Even if the time is not reached, the bearing must be replaced when unu-
sual noise, vibration, or faults are found.
3)
This lifetime is only for reference. When a motor keeps running at 80% rated value and the surrounding air temperature
is 30 °C, the encoder lifetime can be ensured.
