Siemens SINUMERIK 808D ADVANCED Series User Manual

Commissioning Manual
438 6FC5397-4EP10-0BA8, 07/2018
2
Synchronized action with ID...can be blocked from the PLC
ID24
ID23
ID22
ID21
ID20
ID19
ID18
ID17
17.12.3
Reading and writing PLC variables
DB4900
PLC variables [r/w]
PLC interface
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0
Offset [0]
1
Offset [1]
2
Offset [2]
…
…
4094 Offset [4094]
4095
Offset [4095]
Note
The programming engineer (NCK and PLC) is responsible for organizing
(structuring) this memory area. Every storage
position in the memory can be addressed provided that the limit is selected according to the appropriate data format (i.e. a
'DWORD' for a 4byte limit, a WORD for a 2byte limit, etc.). The memory area is alway
s accessed with the information about
the data type and the position offset within the memory area. The PLC variables can be read or written in the NC program
$A_DBB[n] ("n" stands for the position offset in bytes).
17.13
Axis actual values and distance-to-go
DB5700 ...
5704
Signals from axis/spindle [r]
NCK -> PLC interface
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0
Axis actual value (REAL)
4
Axis distance-to-go (REAL)
Note
The ax
is actual values and distances-to-go can be separately requested:
•
DB2600.DBX0001.1 Request axis actual values
•
DB2600.DBX0001.2 Request axis distances-to-go
If the particular request is set, then the NCK supplies these values for all axes.
17.14
Maintenance scheduler: User interface
17.14.1
Initial (start) data
DB9903
Initial data table [r16]
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0
Interval 1 [h]
2
Time of first warning 1 [h]
4
Number of warnings to be output 1
6
Reserved 1
8 Interval 2 [h]
10
Time of first warning 2 [h]
11
Number of warnings to be output 2
14
Reserved 2
...
...
