Siemens SINUMERIK 808D ADVANCED Series User Manual

Commissioning Manual
6FC5397-4EP10-0BA8, 07/2018
373
Horizontal PPU
(161.3/151.3)
Vertical PPU
(160.3/150.3)
Horizontal MCP
Vertical MCP
Ambient operating conditions
Temperature Front: 0 °C to 45 °C
Rear: 0 °C to 50 °C
Relative humidity
5% to 90%, without condensation
Atmospheric pressure
From 1080 hPa to 795 hPa
Vibration resistance (in operation) 10 Hz to 58 Hz: 0.35 mm
58 Hz to 200 Hz: 1g
Shock resistance (in operation) 10 g peak value, 6 ms duration
6 shocks in each of the 3 axes vertical to each other
Certification
CE, KC, RCM, and EAC
1)
For the horizontal MCP with override switches;
2)
For the horizontal MCP with a reserved slot for the handwheel;
3)
For the vertical MCP with an override switch for the spindle;
4)
For the vertical MCP with a reserved slot for the handwheel;
15.2
Servo drives
15.2.1
SINAMICS V70 feed drives
Frame size
FSA
FSB
FSC
Article num-
ber
6SL3210-5DE... 12-4UA0 13-5UA0 16-0UA0 17-8UA0 21-0UA0 21-4UA0 21-8UA0
Rated output current
1.2 A
3.0 A
4.6 A
5.3 A
7.8 A
11.0 A
13.2 A
Max. output current 3.6 A 9.0 A 13.8 A 15.9 A 23.4 A 33.0 A 39.6 A
Max. supported motor power
0.4 kW
1.0 kW
1.5 kW
1.75 kW
2.5 kW
3.5 kW
7.0 kW
Output frequency 0 Hz to 330 Hz
Power supply
Voltage/frequency
3 phase 380 VAC to 480 VAC, 50/60 Hz
Permissible supply
configuration
TN, TT, IT
Permissible voltage
fluctuation
-15% to +10%
Permissible frequency
fluctuation
-10% to +10%
Rated input current
1.5 A
3.8 A
5.8 A
6.6 A
9.8 A
13.8 A
16.5 A
Power supply capacity
1.7 kVA
4.3 kVA
6.6 kVA
7.6 kVA
11.1 kVA
15.7 kVA
18.9 kVA
Inrush current
8.0 A
8.0 A
4.0 A
4.0 A
4.0 A
2.5 A
2.5 A
Power loss
1)
Main circuit
31 W
32 W
76 W
90 W
96 W
115 W
138 W
Control circuit
32 W
32 W
35 W
35 W
35 W
36 W
36 W
Built-in regenerative
resistor
57 W 57 W 131 W 131 W 131 W 339 W 339 W
Total
120 W
121 W
242 W
256 W
262 W
490 W
513 W
24 VDC power
supply
Voltage 24 V (-15% to +20%)
Exception: When the SINAMICS V70 works with a motor with brake, the volt-
age tolerance of 24 VDC power supply must be -10% to +10% to meet the
voltage requirement of the brake.
Maximum current 1 A (when using a motor without a brake)
3 A (when using a motor with a brake)
