Name
Type
Description
ROV
BOOL
ROV in Manual Machine Mode
Outputs
Name
Type
Description
AL_03
BOOL
Not approaching the reference point on axis X (user alarm 03)
AL_04
BOOL
Not approaching the reference point on axis Z (user alarm 04)
AL_09
BOOL
Incorrect start in the spindle direction (user alarm 09)
AL_11
BOOL
JOG program timeout (user alarm 11)
AL_12
BOOL
Spindle rate not 100% (user alarm 12)
AL_13
BOOL
Spindle not being started (user alarm 13)
AL_14
BOOL
Feed rate 0% (user alarm 14)
AL_16 BOOL Spindle direction change in a thread not allowed (user alarm 16)
Assigned global variables
Byte
Signal
Byte 7
Byte 6
Byte 5
Byte 4
Byte 3
Byte 2
Byte 1
Byte 0
MB170 HMI<->MM Request
for MM
HMI
startup
MM HMI
enabled
MM HMI
started
MB171
HMI<->MM
MB172
HMI<->MM
MB173
HMI<->MM
MB174 HMI<->MM Cone an-
gle 270°-
360°
Cone
angle
270°
Cone
angle
180°-270°
Cone
angle
180°
Cone
angle 90°-
180°
Cone
angle 90°
Cone
angle 0°-
90°
Cone
angle 0°
MB175 HMI<->MM Direction
key ena-
bled
Spindle
rotated
MB176 HMI<->MM Working
step ena-
bled
Groove
enabled
Thread
chaining
enabled
Drilling
enabled
Arc ena-
bled
Cutting
enabled
Thread
enabled
MB177 HMI<->MM
MB178
MB179
MB180 Recutting
canceled
Recutting
performed
Recut the
thread or
not?
Relevant PLC machine data
No.
Unit
Range
Description
MD14512[19].7 - - 1: to enable the manual machine function
0: to disable the manual machine function
