Commissioning Manual
196 6FC5397-4EP10-0BA8, 07/2018
Operation not allowed: chuck unclamped
Gear stage change timeout
SBR49: GearChg1_Auto
Gear position signal error
700017 DB1600.DBX2.1 Chuck operation not allowed: spindle/prog.
SBR56: Lock_unlock_T
SBR44: COOLING
Lubricating motor overload
SBR45: LUBRICAT
700021 DB1600.DBX2.5 Lubricant level too low
SBR51: Turret1_HED_T
SBR52: Turret2_BIN_T
SBR53: Turret3_CODE_T
Prog. tool pos. number > max. tool pos. number
Max. tool position number illegal
No tool position signal from turret
Warning: the 1st maintenance task will expire
SBR48: ServPlan
Alarm: the 1st maintenance task has expired
Magazine not in spindle pos. or original pos.
Magazine in spindle pos. and original pos.
700033 DB1600.DBX4.1 Magazine rot. failed: magazine/spindle not
SBR60: Disk_MGZ_M
700034 DB1600.DBX4.2 Blk search finds tool on spindle <> tool pro-
SBR60: Disk_MGZ_M
700035 DB1600.DBX4.3 Spindle positioning to unclamping position
SBR60: Disk_MGZ_M
Spindle positioning to clamping position timeout
Reference point of X axis not reached
Reference point of Z axis not reached
700051 DB1600.DBX6.3 Spindle direction illegal SBR58: MM_MAIN
Monitoring time for JOG operation exceeded
700053 DB1600.DBX6.5 Spindle override not 100% SBR58: MM_MAIN
Spindle dir. change not allowed in thread mach.
700059 DB1600.DBX7.3 NC start not possible: safety door not closed SBR22:
700060 DB1600.DBX7.4 PRT/AFL change not possible: channel not
SBR37: MCP_NCK
Mgz. in maint. Read-in & rapid traverse disabled
700062 DB1600.DBX7.6 Tool on spindle <> tool prgd. mgz. must be
SBR60: Disk_MGZ_M
