Siemens SINUMERIK 808D ADVANCED Series User Manual

Commissioning Manual
432 6FC5397-4EP10-0BA8, 07/2018
Signals to axis
DB3800 ...
3803
Signals to axis [r/w]
PLC -> NCK interface
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
1000 Delay Ref.
pt. ap-
proach
Module limit
enabled
Software limit switch
Hardware limit switch
Plus Minus Plus Minus
1001
1002 Activate
program
test
Suppress
program
test
1003
Signals to spindle
DB3800 ...
3803
Signals to axis [r/w]
PLC -> NCK interface
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
2000 Delete S
value
No speed
monitoring
for gear
change
Resynchronize spindle
Gear
changed
Actual gear stage
2 1 C B A
2001 Invert
M3/M4
Resynchro-
nize during
positioning
Feedrate
override for
spindle
valid
2002 Setpoint direction of rota-
tion
Oscillation
speed
Oscillation
controlled
by PLC
Counter-
clockwise
Clockwise
2003
Spindle override
H
G
F
E
D
C
B
A
Signals to PLC axis
DB3800 ...
3803
Signals to PLC axis [r/w]
PLC -> NCK interface
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
3000 Start axis
positioning
Start spin-
dle posi-
tioning
Start spin-
dle rotation
Start spin-
dle oscilla-
tion
3001 Stop spin-
dle rotation
Stop spin-
dle oscilla-
tion
3002 Automatic
gear selec-
tion
Constant
cutting rate
Direction of
rotation as
for M4
Handwheel
override
Traversing
dimension,
inches (not
metric)
Distance
condition,
shortest
distance
(DC)
Distance
condition,
incremental
(IC)
3003 Indexing
position
Distance
condition,
absolute
positive
direction
(ACP)
Distance
condition,
absolute
negative
direction
(ACN)
