Chapter 19 Control Panel Setup (Panel)
1084
Overall Control Panel Settings (Config Menu)
Disable: Enable only panel display, and disable operation of the bank.
Inhibit: Disable both the panel display and operation of the bank.
Notes
When this is set to Inhibit, snapshots of the bank are not recalled.
Assigning Two M/E Banks to One M/E Bank
1
In the Panel >Config menu, select the M/E bank for which you want to
make the setting.
• Press directly on the list in the status area.
• Press the arrow keys to scroll the reverse video cursor.
• Turn the knob.
a) Depends on the center control panel configuration. When 7 (Ext 3) is selected, or a
switcher bank is selected which is immediately above a switcher bank to which nothing is
assigned, then [Dual M/E Assign] is invalid.
For example, if the furthest bank from you is assigned to M/E-1, and you
want no shift button operation for the bank, select 1 (1st Row) for Bank.
2
Press [Dual M/E Assign].
This assigns the furthest M/E bank from you to the unshifted (shifted)
cross-points and the M/E bank in front of it to the shifted (unshifted) cross-
points. For fader lever operations, only the M/E bank closer to you is
enabled.
The shift/non-shift assignment is set by [Dual M/E Xpt Swap]. For more
details, see the next section, “Interchanging shifted and non-shifted
operations for a dual M/E.”
To return to the original assignment
Interchange the bank order (see page 1083).
Interchanging shifted and non-shifted operations for a dual M/E
1
In the Panel >Config menu, select the M/E bank for which the dual M/E
setting is made.
• Press directly on the list in the status area.
Knob Parameter Adjustment Setting values
1 Bank Selection of position of bank for which you
want to make the setting
1 to 7
a)
To Next Page
