Chapter 19 Control Panel Setup (Panel)
1105
Overall Control Panel Settings (Config Menu)
This assigns the device or function selected in the list to the button.
To cancel an assignment
Select the button, then press [Clear].
This removes the assignment to that button.
To return all device selection button assignments to the factory
default state
In the Joystick/Trackball Module menu, press [Default].
Inhibiting Utility 2 Bus and Key Operations
You can inhibit operations on the utility 2 bus and keys 1 to 8 of the M/E and
PGM/PST banks by menu operations.
This inhibitions apply for the following control blocks.
• Cross-point control block
• Transition control block
• Independent key transition control block
1)
1) Only when the Key1, 2, Key 3, 4, Key5, 6 or Key7, 8 are assigned by the Compact Key Module
Assign menu.
Notes
In the auxiliary bus control block and other control blocks which are excluded
from M/E and PGM/PST banks, the operations on the utility 2 bus and keys 1
to 8 are not inhibited.
1
In the Panel >Config menu, press [Operation Inhibit].
Operation Inhibit menu appears.
2
Press [M/E Operation Inhibit].
The M/E Operation Inhibit menu appears.
3
In the list in the status area, using any of the following methods, select the
switcher bank for which operations are to be inhibited.
• Press directly on the desired switcher bank in the list.
• Press the arrow keys to scroll the reverse video cursor.
• Turn the knob.
Knob Parameter Adjustment Setting values
1 Bank Switcher bank selection for
inhibiting operations
1 and upwards
To Next Page
