Chapter 19 Control Panel Setup (Panel)
1119
Cross-Point Settings (Xpt Assign Menu)
3
Press [Source Name].
A keyboard window appears.
4
Enter any name of not more than 16 characters, then press [Enter].
For details of keyboard window operation, see “Menu Operations” in
Chapter 2 (Volume 1).
Sequential names for multiple signals
When you specify a number at the end of a signal name, all of the signals in the
range selected by knobs 1 and 2 are automatically assigned names ending with
sequential numbers.
Example: To assign sequential names to source signal 2 through source signal
4
1. In step 2 above, set knob 1 to “2,” and set knob 2 to “3.”
2. Set the name of source signal 2 to “CAM2.”
The name “CAM3” is assigned automatically to source signal 3, and the
name “CAM4” is assigned automatically to source signal 4.
Setting the source name display color
1
In the Panel >Xpt Assign >Table Button Assign >Src Name/LCD Color
menu, turn the knobs to select the setting target.
2
In the <LCD Color> group, select the color (Orange/Green/Yellow).
Copying Cross-Point Assign Tables
The contents of a cross-point assign table can be copied to another cross-point
assign table, and vice versa.
Knob Parameter Adjustment Setting values
1 Source No Source signal selection 1 to 228
2 Num Number of source signals to be
selected
1 to 228
Knob Parameter Adjustment Setting values
1 Source No Source signal selection 1 to 228
2 Num Number of source signals to be
selected
1 to 228
