Chapter 19 Control Panel Setup (Panel)
1141
Setting Button Assignments (Prefs/Utility Menu)
1
In the Prefs/Utility >Utility Module Assign menu, select the button using
any of the following methods.
• Press directly on the list.
• Press the arrow keys to scroll the reverse video cursor.
• Turn the knobs.
2
Press [Name].
A keyboard window appears.
3
Enter a name of not more than eight characters, and press [Enter].
The name you have set is reflected in the status area and on the memory
recall button in the utility/shotbox control block.
Assigning a Function to the Key 2 Row Cross-Point
Buttons
You can assign a function to the key 2 row cross-point buttons of each of the
M/E-1 to M/E-4, or PGM/PST banks, and use them in the same way as the
buttons in the utility/shotbox control block.
1
In the Prefs/Utility menu, press [Key2/4 Bus Button Assign].
The Key2/4 Bus Button Assign menu appears. The cross-point settings for
the key 2 row appear.
2
Refer to “Assigning a Function to a Memory Recall Button in the Utility/
Shotbox Control Block” (page 1135) to make the assignment. Note,
however, the following differences.
• The bank setting of knob 1 is from 1 to 5.
• The adjustment range of knob 2 is from 1 to the number of cross-point
buttons.
• The character string for a button name is a maximum of four characters.
For details of executing a utility/shotbox function with the key 2 row, see
“Executing Utilities With the Cross-Point Buttons in the Key 2 Row” (Volume
2) and “Executing a Shotbox Function With the Key 2 Row Cross-Point
Buttons” (Volume 2).
Knob Parameter Adjustment Setting values
1 Bank Bank selection 1 to 4
2 Button No Control block button selection 1 to 24
To Next Page
