Chapter 11 DME Operations
597
DME Special Effect Operations
4
To soften the edges of the image, press [Edge Soft], turning it on, and set
the following parameter.
Notes
Edges cannot be softened when the Crop effect is disabled.
To specify whether to invert the crop area when inverting the video
In the <Invert/Crop Process> group, select either of the following.
Crop –> Invert: Set an axis of symmetry at the center of the input video, and
invert both the desired area of video and the crop area horizontally and
vertically around that axis of symmetry. The order of effect application is
Crop > Invert.
Invert –> Crop: Set an axis of symmetry at the center of the input video, and
invert only the desired area of video horizontally and vertically around that
axis of symmetry. The order of effect application is Invert > Crop.
Beveled Edge Settings
Applying a beveled edge
1
In the DME menu, select VF1 ‘Edge’ and HF2 ‘Beveled Edge.’
The Beveled Edge menu appears.
2
Press [Beveled Edge], turning it on.
This enables the beveled edge, and you can now use the knobs to adjust the
parameters.
Notes
When the border is enabled, the edge soft function (see page 595) is not
available.
3
Set the parameters.
The valid ranges of the parameter values depend on the combination of
signal format (SD/HD) and aspect ratio (4:3/16:9) selected in the system,
as follows.
Knob Parameter Adjustment Setting values
1 Soft Softness of edges 0.00 to 100.00
To Next Page
