Chapter 2 Menus and Control Panel
84
Names and Functions of Parts of the Control Panel
for M/E-4 Selection in the Setup Menu”
(page 542) in Appendix (Volume 1).
DME V (DME monitor video): When this
button is pressed, the DME monitor
output video signal (DME MON V) is
selected on the edit preview bus.
DME K (DME monitor key): When this
button is pressed, the DME monitor
output key signal (DME MON K) is
selected on the edit preview bus.
c AUTO button
When this button is pressed, the M/E or
PGM/PST bank preview signal selected on
the edit preview bus is automatically
switched to the program signal depending
on the on-air status.
Auxiliary Bus Control Block (for AUX Buses)
There are also models without the selected
source name displays and source name
displays shown in the following figure.
All operations except those of the [DEST]
button and [SHIFT] button are the same as
for a model with selected source name
displays and source name displays.
To Next Page
