Chapter 11 DME Operations
712
Global Effect Operations
2
In the menu control block, press the top menu selection button [GLB EFF],
then select VF1 ‘Ch1 - Ch4.’
The Global Effect >Ch1 - Ch4 menu appears.
Combiner Settings
When multiple channels are selected on one keyer or for one transition, the
Combiner automatically combines the selected images. Up to four channels
can be combined.
You can also control the way in which the combination is carried out, as a mix
or an overlap with priority set automatically. For a mix, you can control the
relative amounts of each channel.
Images can also be crossed in three dimensions.
Notes
Three-dimensional image crossing is not supported on the MVE-8000A.
Combination of channel 1 (Ch1) and channel 2 (Ch2)
Combiner
To Next Page
