Chapter 19 Control Panel Setup (Panel)
1104
Overall Control Panel Settings (Config Menu)
To return all device selection button assignments to the factory
default state
In the Device Control Module menu, press [Default].
Assigning devices and functions to the region selection buttons
of the device control block (trackball)/device control block
(joystick)
You can assign devices and functions to the region selection buttons of the
device control block (trackball)/device control block (joystick).
For details of the device control block (trackball)/device control block
(joystick), see Chapter 2 (Volume 1).
1
In the Panel >Config menu, press [Link/Program Button].
The Link/Program Button menu appears.
2
Press [Joystick/Trackball Module].
The Joystick/Trackball Module menu appears.
3
In the lower right <Mode Select> group, select [Device/Clip] or [Wipe/
RSZR].
Device/Clip: Assignment while the device control block DEV button is lit
Wipe/RSZR: Assignment while no button is lit on the device control
block or the RSZR button is lit
According to the selection, the left of the status area shows the region
selection buttons of the device control block. The list on the right shows
the devices and functions that can be assigned.
4
In the button displays on the left, press the button for the assignment.
5
Using any of the following methods, select the device or function to be
assigned.
• Press directly on the list on the right.
• In the list on the right, press the arrow keys to scroll the reverse video
cursor.
• Turn the knob.
6
Press [Set].
Knob Parameter Adjustment Setting values
1 Function Selection of device or
function to be assigned
1 and upwards
To Next Page
