Chapter 21 DME Setup (DME)
1219
Interfacing With External Devices (Device Interface Menu)
The selected setting appears in the status area.
Selectable actions for various trigger types
• When the trigger type is other than “Level”
When Target is Ch1, Ch2, Ch3, or Ch4: Freeze, SS ? Recall
Effect ? Recall, Effect ? Recall & Run, KF Run, KF Stop, KF Rewind,
KF Reverse Run, No Action
When Target is Proc: No Action
• When the trigger type is “Level”
When Target is Ch1, Ch2, Ch3, or Ch4: Aspect, No Action
When Target is Proc: Format Aspect, Level Enable, No Action
Notes
“Level Enable” is a function that determines whether GPI inputs are enabled
(“Enable”) or disabled (“Disable”) for the “Aspect” and “Format” actions that
can be used when the trigger type is Level. When Level Enable is used, if the
input is “Disable” then it is not possible to switch “Aspect” or “Format” by GPI
input.
If a GPI to switch “Aspect” or “Format” occurs when powering the system off,
the action triggered by the GPI may start immediately before the power goes
off and the power may go off before the action is completed. This may corrupt
the setup settings. It is therefore recommended to use Level Enable to avoid
such a situation.
Carrying out level settings
To set the low level and high level, first set the trigger type to “Level,” then use
the following procedure.
1
In the DME >Device Interface menu, select the action to be set, and press
[H/L Set].
The H/L Set menu appears.
2
Using any of the following methods, select the settings.
• Press directly on the list in the status area.
• Press the arrow keys to scroll the reverse video cursor.
• Turn the knob.
3
To apply the selection made in step 2 when the input is high, press [H Set].
To apply the selection made in step 2 when the input is low, press [L Set].
Knob Parameter Adjustment Setting values
1 No Signal format/screen aspect ratio
selection
1 and upwards
To Next Page
