Chapter 4 Keys
240
Key Setting Operations Using Menus
Using the main mask
For example, to use the main mask for key 1 on the M/E-1 bank, use the
following procedure.
1
In the M/E-1 >Key1 menu, select HF3 ‘Main Mask.’
The Main Mask menu appears.
2
In the <Mask Type> group, select the mask type.
Key Mask: Masks a part of a key.
Bkgd Mask: Masks a part of a background.
3
In the <Mask Source> group, select the mask source.
Box: signal from the dedicated box generator
Pattern: signal from the dedicated pattern generator
4
Set the mask source parameters.
• When a box is selected
• When a pattern is selected
a) The pattern is the same as a standard wipe. (See “Wipe Pattern List” in Appendix (Volume
1) (page 496).)
To select the pattern, display the Mask Ptn Select menu by pressing the
[Mask Ptn Select] button in the Main Mask menu.
After selecting one of the patterns (standard wipe patterns 1 to 24)
displayed in the Mask Ptn Select menu, you can adjust the following
parameters.
Knob Parameter Adjustment Setting values
1 Top Top position –100.00 to +100.00
2 Left Left position –100.00 to +100.00
3 Right Right position –100.00 to +100.00
4 Bottom Bottom position –100.00 to +100.00
5 Soft Box softness 0.00 to 100.00
Knob Parameter Adjustment Setting values
1 Size Pattern size 0.00 to 100.00
2 Soft Edge softness 0.00 to 100.00
5 Pattern Pattern number
1 to 24
a)
To Next Page
