Chapter 4 Keys
285
Key Snapshots
Saving a key snapshot
For example, the following procedure saves the state of the M/E-1 key 1
settings.
1
In the M/E-1 independent key transition control block, press the key
delegation button [KEY1], turning it on.
2
Press the [K-SS] button, turning it on.
The system switches to key snapshot mode, and the key source name
display/key snapshot buttons show the status of registers 1 to 4 for key 1.
Off: Nothing is saved in the register.
Lit orange: Settings are saved in the register.
For a register holding a snapshot, the register name is shown as up to eight
characters.
3
Hold down the [K-SS STORE] button, and press the key source name
display/key snapshot button corresponding to the register in which you
want to save the snapshot.
The key source name display/key snapshot button which you pressed lights
yellow.
Notes
If you save a key snapshot in a register for which the button is lit orange or
yellow, the existing contents of the register are overwritten.
Recalling a key snapshot
For example, the following procedure recalls the state of the M/E-1 key 1
settings.
1
In the M/E-1 independent key transition control block, press the key
delegation button [KEY1], turning it on.
2
Press the [K-SS] button, turning it on.
3
Set the following buttons on or off, depending on the information you want
to recall.
(These buttons are not provided in the downstream key control block.)
[K-MOD ENBL] button: When this is on, the key settings and key
modifiers are recalled. When this is off, they are not recalled.
[K-TR ENBL] button: When this is on, the independent key transition
settings are recalled. When this is off, they are not recalled.
To Next Page
