Chapter 5 Wipes
333
Wipe Pattern Operations in the Multifunction Flexi Pad Control Block
• When soft edge is selected
• When edge matte is selected
Buttons for positioning the wipe pattern
POS (position): Adjusts the position of the wipe pattern.
CNTR (center): Returns the wipe pattern position to the center.
When you press the [POS] button, the alphanumeric display first shows the
name of the parameter, “H” or “V,” and then the value of the parameter.
When the [POS] button is lit green, you can adjust the position of the wipe
pattern with the control knobs.
Buttons for setting the wipe direction
NORM (normal): Sets wipe to normal (forward) direction.
NORM/REV (normal/reverse): Sets the wipe direction to alternate between
normal and reverse for each transition.
REV (reverse): Sets wipe to reverse direction to normal.
3 O Degree of softening of
outside of border
0 to100
Parameter group [1/2]
Knob Parameter Adjustment Setting values
Parameter group [2/2]
Knob Parameter Adjustment Setting values
1 L Luminance 0 to 100
2 S Saturation 0 to 100
3 H Hue 359 to 0
Knob Parameter Adjustment Setting values
1 S Degree of softening of
edge
0 to 100
Knob Parameter Adjustment Setting values
1 L Luminance 0 to 100
2 S Saturation 0 to 100
3 H Hue 359 to 0
Knob Parameter Adjustment Setting values
1 H Horizontal position –200 to +200
2 V Vertical position –200 to +200
