Chapter 8 Color Backgrounds, Copy and Swap, and Other Settings
437
Copy and Swap
DME channel copy and swap
You can copy and swap the channel data among DME channels 1 to 4 or DME
channels 5 to 8.
It is not possible to copy or swap the channel data between DME channels 1 to
4 and DME channels 5 to 8.
Notes
When the signal format is 1080P, the combinations for a copy or swap
operation are limited to the following.
• Channels 1 and 2
• Channels 3 and 4
• Channels 5 and 6
• Channels 7 and 8
Copying format converter data
You can copy data from one format converter input to another or from one
output to another.
Color background • Colors 1 and 2 for color background 1
• Colors 1 and 2 for color background 2
Frame memory • FM1 color
• FM2 color
DME ch1 to ch8 • Background
•Border
• Sepia
• Light
• Shade
• Drop shadow (other than DME ch4 and DME ch8)
•Trail
Target bank Target keyer and data
To Next Page
