Chapter 9 Color Corrector
455
Preparations
Selecting the color correction input signal
After assigning CCR1 and CCR2 to AUX buses, use the following procedure.
1
Press the AUX delegation buttons assigned to CCR1 (or CCR2).
2
In the cross-point button row, select the signal to which you want to apply
color correction.
Notes
The signals that can be selected on the CCR1 and CCR2 buses are primary
inputs, premium inputs, format converter inputs and frame memory
outputs (FM1 to FM8) only.
However you can make all the internal signals of the switcher selectable
by a setting in the Setup menu.
For details, see “Selecting the Bank to Make the Settings” in Chapter 20
(Volume 3).
Selecting the color corrector output signal
By assigning the signal output from the color corrector to a cross-point button,
you can make that signal available on that button.
For details of the assignment process, see “Cross-Point Settings (Xpt Assign
Menu)” in Chapter 19 (Volume 3).
Accessing the CCR menu
For color correction operations, use the CCR menu.
To access the CCR menu, in the menu control block, press the top menu
selection button [CCR].
The following description uses CCR1 as an example. To apply color correction
to CCR2, replace VF1 ‘CCR1’ by VF2 ‘CCR2,’ and follow the same
procedure.
