Chapter 9 Color Corrector
462
Color Corrector Functions
a) See “Setting the wipe position (Positioner)” (page 306).
• When turning [Multi] on and replicating the same pattern
a) See “Setting the wipe pattern replication (Multi)” (page 311).
• When turning [Aspect] on and setting the aspect ratio of the pattern
a) See “Setting the wipe pattern aspect ratio (Aspect ratio)” (page 310).
• When turning the [Angle] on in the <Rotation> group and slanting
the pattern
a) See “Angle” (page 308).
• When turning [Speed] on in the <Rotation> group and rotating the
pattern at a fixed rate
a) See “Speed” (page 309).
7
To invert the mask source, return to the Primary CCR menu and press [Pri/
Sec Mask Invrt], turning it on.
Notes
The mask function is common to the primary color correction, secondary color
correction, and spot color adjustment functions.
Knob Parameter Adjustment Setting values
1 H Multi Number of repetitions of pattern
horizontally
1 to 63
2 V Multi Number of repetitions of pattern
vertically
1 to 63
3 Invert Type Replication layout
1 to 4
a)
Knob Parameter Adjustment Setting values
1 Aspect aspect ratio
–100.00 to +100.00
a)
Knob Parameter Adjustment Setting values
1 Angle Angle of pattern rotation
–100.00 to +100.00
a)
Knob Parameter Adjustment Setting values
1 Speed Rotation rate of pattern
–100.00 to +100.00
a)
