Chapter 11 DME Operations
620
DME Special Effect Operations
Creating a color combination pattern
To select the pattern
1
In the DME menu, select VF1 ‘Edge’ and HF7 ‘Color Mix.’
The Color Mix menu appears.
2
Press [Mix Pattern Select].
The Mix Pattern Select menu appears.
3
Press any of the displayed patterns (standard wipe patterns 1 to 24) to
select it.
In this state, you can adjust the pattern size and border softness with the
knobs.
(For details of the parameters, see the next item.)
To set the pattern size and position
1
In the Color Mix menu, press [Position/Size].
2
Set the following parameters.
The setting range for the parameters depends on the system selected signal
format (SD/HD) and aspect ratio (4:3/16:9), as follows.
•For SD format
a) For 4:3 mode
b) For 16:9 mode
• For HD format
Knob Parameter Adjustment Setting values
1 H Horizontal position –8.00 to +8.00
2 V Vertical position
–6.00 to +6.00
a)
–4.50 to +4.50
b)
3 Size Pattern size 0.00 to 100.00
4 Soft Softness of the pattern 0.00 to 100.00
5 Pattern Pattern number 1 to 24
Knob Parameter Adjustment Setting values
1 H Horizontal position
–24.00 to +24.00
a)
–32.00 to +32.00
b)
To Next Page
