Chapter 13 Keyframe Effects
767
Regions
outputs. The settings made for frame memory images in the Freeze menu or
other menus do not apply to snapshots or keyframes.
• To reproduce a frame memory still image or a clip of them by recalling a
snapshot or keyframe, you must have the same images that were present in
the frame memory when you saved the snapshot or keyframe. Therefore,
when saving a snapshot or keyframe using frame memory, you must also
save the images to a storage media such as the hard disk.
Reference region
When multiple regions are selected, only one region appears in the displays for
menu and numeric keypad operations. This is called the “reference region.”
The reference region is determined according to the following precedence.
M/E1 >M/E2 >M/E3 >M/E4 >P/P >User1 >User2 >User3 >User4 >User5
>User6 >User7 >User8 >DME ch1>DME ch2 >DME ch3 >DME ch4
>DME ch5 >DME ch6 >DME ch7 >DME ch8 >Device1 >Device2
>Device3 >Device4 >Device5 >Device6 >Device7 >Device8 >Device9
>Device10 >Device11 >Device12 >P-Bus >GPI >Router >Macro
Master region
The regions saved in a master snapshot register or master timeline register and
the register numbers saved in such regions can be recalled at a time as the
master region.
The master region can be saved or recalled using the numeric keypad control
block or Multifunction Flexi Pad control block.
