Chapter 17 Files

997

Operations on Individual Files

In the operating device selection section on the left or right, select

[Register].

The register name “FM_Bkup” appears. In the device selection section on

the opposite side, the destination for saving automatically appears.

As the destination for saving select [HDD] or [Memory Card], then specify

the directory.

Select the destination file for saving.

• To save to disk, press ‘Save.’

• To load from disk, press ‘Load.’

To view details of files

Press ‘File Edit.’

A list of the saved file names appears. You can manipulate these files like any

other files.
